| Part Number(s) |
9551-62, 9552-62, 9553-67, 9556-72, 9557-72, 9558-77 |
| Brand |
Bezdan Stainless, Bezdan Stainless, Bezdan Stainless, Bezdan Stainless, Bezdan Stainless, Bezdan Stainless |
| Product Type |
Pre-assembled posts, Pre-assembled posts, Pre-assembled posts, Pre-assembled posts, Pre-assembled posts, Pre-assembled posts |
| Application |
End, Center, Corner, End, Center, Corner |
| Material |
Stainless Steel, Stainless Steel, Stainless Steel, Stainless Steel, Stainless Steel, Stainless Steel |
| Alloy |
304, 304, 304, 304, 304, 304 |
| Finish |
#4 Satin, #4 Satin, #4 Satin, #4 Satin, #4 Satin, #4 Satin |
| Finishing Process |
Brushed, Brushed, Brushed, Brushed, Brushed, Brushed |
| Color |
Stainless Steel, Stainless Steel, Stainless Steel, Black Stainless, Black Stainless, Black Stainless |
| Post Type |
1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078" |
| Post Size |
1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078", 1-9/16" x 1-9/16" x 0.078" |
| Post Height |
34.5", 34.5", 34.5", 34.5", 34.5", 34.5" |
| Post Placement on Tread |
Front, Front, Front, Front, Front, Front |
| Bracket Height |
1.94", 1.94", 1.94", 1.94", 1.94", 1.94" |
| Total Height |
36.44", 36.44", 36.44", 36.44", 36.44", 36.44" |
| Post Configuration |
End, End |
| Saddle Type |
Flat, Flat, Flat, Flat, Flat, Flat |
| Glass Size (T) |
8, 10, 12mm, 8, 10, 12mm, 8, 10, 12mm, 8, 10, 12mm, 8, 10, 12mm, 8, 10, 12mm |
| Clip Size |
Medium, Medium, Medium, Medium, Medium, Medium |
| Clip Style |
Square, Square, Square, Square, Square, Square |
| Diameter |
1-9/16", 1-9/16", 1-9/16", 1-9/16", 1-9/16", 1-9/16" |
| Weight (lbs) |
7.41, 8.87, 8.92, 7.55, 9.15, 9.83, |
| Certifications |
Meets ASTM A554 standard, Meets ASTM A554 standard, Meets ASTM A554 standard, Meets ASTM A554 standard, Meets ASTM A554 standard, Meets ASTM A554 standard |
